TH1080/SP Injection Molding Machine
TH1080/SP injection molding machine adopts brand name and is supplemented by hydraulic system and electrical system. Its product performance is stable, and various engineering operations are simple. It is widely used in aerospace, high-speed rail, automotive electronics, urban construction, people’s livelihood and other fields. This series of fast and precise servo energy-saving injection molding machines is equipped with a pressure feedback device with strong precision and sensitivity, forming a closed-loop precision control and providing customers with good product stability. Compared with traditional hydraulic presses, it shows stronger injection stability, greatly improves the qualified rate of molded products, saves energy and protects the environment, responds quickly, effectively shortens the cycle, and improves production efficiency.
Add to quoteITEMS | Units | TH1080/SP | ||||
A | B | C | D | |||
INJECTION UNIT | Screw Diameter | mm | 100 | 110 | 120 | 130 |
| Screw L/D Ratio | L/D | 24.2 | 22．0 | 20.2 | 18.6 | |
| Theoretical injection Volume | cm3 | 4319.7 | 5226.8 | 6220.3 | 7300.3 | |
| Injection Weight (PS) | g | 3930.9 | 4756.4 | 5660.5 | 6643.2 | |
| Injection Pressure | Mpa | 220.2 | 181.9 | 152.9 | 130.3 | |
CLAMPING UNIT | Clamping Force | KN | 10800 | |||
| Clamping Stroke | mm | 1230 | ||||
| Space Between Tie Bar | mm | 1180×1180 | ||||
| Max. Mold Height | mm | 1180 | ||||
| Min. Mold Height | mm | 500 | ||||
| Eject Stroke | mm | 350 | ||||
| Eject Force | KN | 270 | ||||
OTHERS | Max. Pump Pressure | MPa | 16 | |||
| Approx. Motor Power | KW | 86.9/98.2 | ||||
| Approx. Heat power | KW | 73 | ||||
| Hopper Capacity | L | 200 | ||||
| Dimensions | M | 12.6×2.6×2.9 | ||||
| Approx. Machine Weight | T | 49 | ||||
| Oil Tank Capacity | L | 1300 | ||||
Our company's TH1080/sp servo energy-saving injection molding machine can be used to produce plastic beach chairs, and other new environmentally friendly households. This series of models adopts a double-cylinder balanced injection system. The injection control adopts a displacement sensor of a famous foreign brand to accurately control the injection weight. The pre-molding adopts a five-star motor, which can realize stepless speed regulation. The servo drive system adopts the internationally renowned brand driver, and adopts the special control system of the imported injection molding machine. With the rapid development of the plastics industry and the continuous introduction of various new technologies and new plastic materials, the production and processing of plastic packaging, auto parts, various home appliance shells and even new environmentally friendly household items have entered a new period. Welcome friends from all walks of life to visit Tongjia Heavy Industry Co., Ltd. to inspect the injection molding machine equipment, and wholeheartedly provide you with more reasonable servo injection molding machine models and production plan guidance suggestions.
