TH140/SP Injection Molding Machine
TH140/SP injection molding machine adopts brand name and is supplemented by hydraulic system and electrical system. Its product performance is stable, and various engineering operations are simple. It is widely used in aerospace, high-speed rail, automotive electronics, urban construction, people’s livelihood and other fields. This series of fast and precise servo energy-saving injection molding machines is equipped with a pressure feedback device with strong precision and sensitivity, forming a closed-loop precision control and providing customers with good product stability. Compared with traditional hydraulic presses, it shows stronger injection stability, greatly improves the qualified rate of molded products, saves energy and protects the environment, responds quickly, effectively shortens the cycle, and improves production efficiency.
Add to quoteITEMS | Units | TH140/SP | |||
A | B | C | |||
INJECTION UNIT | Screw Diameter | mm | 38 | 42 | 45 |
| Screw L/D Ratio | L/D | 22.1 | 20.0 | 18.7 | |
| Theoretical injection Volume | cm3 | 221.2 | 270.2 | 310.1 | |
| Injection Weight (PS) | g | 201.2 | 245.8 | 282.2 | |
| Injection Pressure | Mpa | 232.7 | 190.5 | 165.9 | |
CLAMPING UNIT | Clamping Force | KN | 1400 | ||
| Clamping Stroke | mm | 430 | |||
| Space Between Tie Bar | mm | 420×420 | |||
| Max. Mold Height | mm | 460 | |||
| Min. Mold Height | mm | 160 | |||
| Eject Stroke | mm | 120 | |||
| Eject Force | KN | 42 | |||
OTHERS | Max. Pump Pressure | MPa | 17.5 | ||
| Approx. Motor Power | KW | 14.7/15.7 | |||
| Approx. Heat power | KW | 9.6 | |||
| Hopper Capacity | L | 25 | |||
| Oil Tank Capacity | L | 200 | |||
| Dimensions | M | 4.7×1.31×1.9 | |||
| Approx. Machine Weight | T | 4.5 | |||
TH140/SP servo energy-saving injection molding machine can produce injection molding products in the range of tile wrapping, switch box, plastic milk carton handle, etc. Take tile wrapping as an example, one mold can produce 10, four to five molds per minute. TH140/SP servo energy-saving injection molding machine is fast, time-saving and power-saving, easy to operate, and fully computer-controlled, which further enhances the competitiveness of customers' products. This series of models adopts a double-cylinder balanced injection system. The injection control adopts a displacement sensor of a well-known foreign brand to accurately control the injection weight. The pre-molding adopts a five-star motor, which can realize stepless speed regulation. The servo drive system adopts the international famous brand driver, and adopts the special control system of imported injection molding machine. The clamping part adopts an advanced five-pivot force-increasing structure with inclined rows. The clamping part has good rigidity, fast mold closing stability, and low pressure mold retention is accurate. It is very suitable for the injection production of small plastic parts.
